Product Code |
d
mm
|
d1
mm
|
B
mm
|
di
mm
|
H1
mm
|
L
|
LS
mm
|
Pressure Rating Water
|
Suitable Pipes
|
Weight
g
|
Unit Per Bag
|
---|---|---|---|---|---|---|---|---|---|---|---|
4658S3500250 | 500 | 250 | 395 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 | 3800 | 1 |
4658S3500315 | 500 | 315 | 444 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 | 9860 | 1 |
4658S3500200 | 500 | 200 | 370 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 | 5760 | 1 |
4658S3630315 | 630 | 315 | 468 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 to SDR 33 | 5700 | 1 |
4658S3630200 | 630 | 200 | 380 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 to SDR 33 | 5330 | 1 |
4658S3630250 | 630 | 250 | 411 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 to SDR 33 | 6850 | 1 |
4658S3710315 | 710 | 315 | 477 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 to SDR 33 | 9590 | 1 |
4658S3710200 | 710 | 200 | 385 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 to SDR 33 | 2860 | 1 |
4658S3710250 | 710 | 250 | 416 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 to SDR 33 | 6690 | 1 |
4658S3800250 | 800 | 250 | 419 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 to SDR 33 | 3670 | 1 |
4658S3800200 | 800 | 200 | 390 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 to SDR 33 | 2680 | 1 |
4658S3800315 | 800 | 315 | 483 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 to SDR 33 | 9520 | 1 |
4658S3900250 | 900 | 250 | 423 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 to SDR 33 | 3670 | 1 |
4658S3900315 | 900 | 315 | 488 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 to SDR 33 | 5880 | 1 |
4658S3900200 | 900 | 200 | 393 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 to SDR 33 | 2700 | 1 |
4658S31000250 | 1000 | 250 | 427 | 231 | 205 | 430 | 188 | PN 6.4 | SDR 26 to SDR 33 | 3670 | 1 |
4658S31000315 | 1000 | 315 | 490 | 291 | 226 | 500 | 208 | PN 6.4 | SDR 26 to SDR 33 | 7050 | 1 |
4658S31000200 | 1000 | 200 | 396 | 185 | 191 | 400 | 173 | PN 6.4 | SDR 26 to SDR 33 | 5800 | 1 |
